Lens barrel swinging machine
model：JKA060
Data download
Return to list
Product features
Arrange the disordered mirrors to the discharge port through the vibrating plate. Use the manipulator to place the corresponding lens barrel into the tray in order. The pallet is loaded with spring clips.
Specification parameters
Equipment capacity UPH > 1200 Pcs/H
Placement yield ≥99.8%
Manipulator accuracy ±0.01mm
Z-axis accuracy ±0.01mm
Movement accuracy of material tray and bin manipulator ±0.01mm
Equipment advantages 1) The equipment has simple structure, easy maintenance and high compatibility; 2) Equipment capacity & stability leading the industry level; 3) The use of clip loading method can reduce workshop operators and reduce operation workload.
Air source 0.3~0.7MPa
Power supply and rated power AC220V 50/60HZ, 2KW
Vacuum source 0~-100Kpa
Application scope
It is applicable to the mirror simple swing plate process in the production of mobile phone cameras.
It is applicable to the mirror simple swing plate process in the production of VR cameras.
It is applicable to the mirror simple swing plate process in the production of vehicle mounted cameras.
