Mobile phone lens turntable
model：JKA046
Data download
Return to list
Product features
The main function of the device is to transfer the assembled lens from the assembly disk to the tray instead of manually.
The assembly tray is fed by the conveyor belt, and the cartridge is automatically received; Tray adopts automatic loading and unloading mode of silo; The material transfer chuck mechanism adopts a multi chuck design, which can suck and place 20 lenses at a time, with high material transfer efficiency.
Specification parameters
Equipment capacity UPH > 5000Pcs/H
Equipment control mode PC + motion control card + display
Repetitive positioning accuracy of linear module ±5μm
Turntable yield 99.7%
Loading and unloading method Automatic feeding
Suction nozzle transfer mode Simultaneous suction and discharge with multiple suction nozzles
Air source 0.3~0.7MPa
Power supply and rated power AC 220V 50/60Hz, 5KW
Vacuum source 0~-100KPa
Equipment advantages 1. Multiple suction nozzles simultaneously suck, discharge and transfer materials with high efficiency and high equipment capacity 2. Automatic loading and unloading of silos and cartridges, saving labor
Application scope
It is suitable for automatic loading and unloading and classified storage of various types of mirrors.
